Features
FPV LCD RX & DVR
8 inch, 32CH
Built-in 5.8G four diversity receiver automatically for best reception
Built-in 2 CH 5.8G AV output and 1CH AV input
Product Details
FPV LCD RX &DVR
Frequency:32 CH
Screen size:8 inch(4:3)
screen type:TFT LCD screen/long life, LED backlight
Resolution:800X600
Brightness:350 cd/m2
Contrast:500:1
View angle:140/120degree(Horizontal/Vertical)
Working Voltage:DV 7-24V
Power consumption:< 10w
Size:200x173x36mm
Working Temp:-10 - +65 degrees
Built-in 5.8G Four diversity receiver automatically for
best reception
Built-in 2 CH 5.8G AV output and 1CH AV input
DVR
Video resolution:640x480 (30 fps)
Memory capacity:Micro SD
